Legality
All use of force must be established in domestic law that meets human rights standards. Officers may only deploy weapons that are lawfully authorized, and the legal framework governing force must be publicly available.
Loading the report…
“ICE Agents Use Less Lethal Force on Nicollet Ave, Minneapolis” by Chad Davis, CC BY 4.0
June 1, 2025 - May 31, 2026
Geographic reach
Who was targeted?
Named enforcement operation
Largely informal; no DHS press release. Branded through Border Patrol Chief Gregory Bovino's personal social media as "Operation at Large" First Bovino-led LA enforcement. It included the deployment of National Guard troops to “protect federal property.”
Named enforcement operation
Formal DHS press release on September 8, 2025. Public messaging by Secretary of Homeland Security Kristi Noem and Assistant Secretary for Public Affairs Tricia McLaughlin Targeted Illinois sanctuary jurisdictions. DHS claimed ~4,500 arrests
Named enforcement operation
DHS released most details on April 15, 2026, after the operation ended. Acting ICE Director Todd Lyons was the public face. Started the same day President Trump federalized the Oregon National Guard. 100+ federal officers were employed, and 1,100+ arrests occurred across the state.
Named enforcement operation
Formal DHS announcement. Billed as the largest immigration enforcement effort in DHS history. ~3,000 federal agents (2,000 ICE plus 1,000 CBP). DHS reported 2,500+ arrests by mid-January. Two shooting deaths occurred during the operation: those of Alex Pretti and Renee Good.
Crowd-control pepper spray canisters like the MK-9 are a different category of weapon from the duty-belt pepper spray carried by patrol officers or the canisters sold to civilians for self-defense — not simply a larger version of either as is often mistakenly assumed (see comparison table). The trigger handle, the size and capacity, and the fog and vapor alternatives underscore that this weapon is designed to be used not against specific threats but indiscriminately against groups, often people exercising their right to free assembly.
| Feature | MK-9 (Crowd-control used by DHS) | Police Duty Spray (MK-3 / MK-4) | Civilian Spray |
|---|---|---|---|
| Primary use | Crowd-control and cell extractions | Standard duty-belt spray | Personal self-defense |
| Size | 9–10.5" tall, ~2.6" diameter | 6–6.6" tall, ~1.5" diameter | 3–4.5" tall, ~1" diameter |
| Fluid volume | 12–18.5 oz | 1.5–3 oz | 0.5–1.8 oz |
| Effective range | 18–30 ft | 10–18 ft | 10–12 ft |
| Minimum range | 6 feet | 3 feet | Not specified |
| Spray pattern |
Stream, cone/fog, or vapor cloud is highly indiscriminate and comes with a higher volume. Note: a sustained pistol-grip trigger allows for sustained spraying. |
Stream or cone can injure individuals or small groups. Typically sprays in short bursts. |
Stream or gel that typically sprays in short bursts. |
| Injury risks |
|
|
|
Each figure represents one documented incident · n = 412
Injury type
Click a highlighted area to see that injury type's weapon breakdown.
In focus
TODO: case studies (currently hidden).
| Amendment | Claim | Tests and Standards | Court Opinions | Relevance to the Findings |
|---|---|---|---|---|
|
First Amendment Protects freedom of speech, assembly, press, religion, and petition. |
Petitioners have argued that the use of crowd-control weapons may be seen as retaliation against the exercise of freedom of speech or assembly. The First Amendment is also implicated when law enforcement actions create a “chilling effect” in which protesters and journalists become afraid to exercise their First Amendment rights due to credible threats of retaliation. |
Successful claims must show that retaliatory animus or intent directly resulted in the injury of a person engaged in a protected activity. |
Opinions have established that crowd-control weapons misuse can, at least circumstantially, suggest retaliatory intent. Index Newspapers LLC v. U.S. Marshals Service (2020): crowd-control weapons misuse, including shots at the head and direct fire of tear gas canisters and pepperballs, can constitute circumstantial evidence of retaliation. Los Angeles Press Club v. Noem (2026): The Ninth Circuit agreed with a District Court ruling that direct fire and shots to the head raise an inference of retaliation. |
For journalists, First Amendment cases focus almost exclusively on allegations of retaliatory intent, which crowd-control weapons misuse can help establish. |
|
Fourth Amendment Protects against unreasonable searches and seizures by the government. |
Petitioners have argued that excessive force (such as law enforcement violence against protesters) can constitute an unreasonable seizure. |
Use of force must be objectively reasonable (Graham v. Connor). The standard asks whether a reasonable officer would act similarly under the same circumstances. To determine this, courts look at the totality of the circumstances, meaning they consider all the factors leading up to and including the use of force by an officer. (Barnes v. Felix). |
Defendants have argued that crowd dispersal does not constitute a “seizure,” but several courts have affirmed that force severe enough to incapacitate an individual, restraining movement just as an arrest would, falls under the Fourth Amendment. Chicago Headline Club v. Noem (2025): Crowd dispersal alone may not constitute seizure, but the District Court found that targeting body parts where only deadly force would be permitted (e.g., the head) shows intent to incapacitate and restrain, constituting seizure. Cheairs v. City of Seattle (2025): Close-range stun grenade detonations can constitute an incapacitating seizure. Sanderlin v. Dwyer (2024): Shots to the groin can constitute an incapacitating seizure. Nelson v. City of Davis (2012): Shots to the head can constitute an incapacitating seizure. |
The term “misuse” as defined in this study does not neatly fit into the Fourth Amendment test. The Fourth Amendment may be implicated where the misuse of a weapon in a manner that violates the standards of law enforcement’s use of force policy or the manufacturer’s standard would be compelling evidence that the actions of an officer are not “objectively reasonable.” Therefore, many of the incidents described may be unreasonable and thus be categorized as excessive use of force. |
|
Fifth and Fourteenth Amendments Protect against arbitrary deprivation of life, liberty, or property without due process. The Fifth Amendment applies to federal action, the Fourteenth to state and local action. |
Plaintiffs have argued that the use of crowd-control weapons violates the due process clause by infringing on their right to bodily integrity. Excessive force may instead be evaluated as a due process question. Note: While many cases related to the use of crowd-control weapons at protests invoke the Fourth Amendment, some also include claims of substantive due process violation. |
The test asks whether the conduct shocks the contemporary conscience or constitutes conduct intended to injure in a manner that is unjustifiable by any government interest (County of Sacramento v. Lewis). |
Harming individuals, particularly vulnerable groups like children or pregnant individuals, may violate due process if law enforcement actions shock the conscience of the judge, jury, or other finders of fact. Chicago Headline Club v. Noem (2025): District Court identified close-range use of impact projectiles and the use of chemical irritants against vulnerable populations (e.g., pregnant individuals, children, and babies) as conscience-shocking behaviors that potentially violate the right to substantive due process. |
Several of our categories of misuse are directly informative for the shocks-the-conscience test, particularly close-range impact projectile use, and indiscriminate chemical agent deployment near vulnerable people. |
|
Other Claims: Federal Tort Claims Act (FTCA) Statutory pathway for suing the federal government over negligence committed by federal employees acting within the scope of their employment. State Negligence Laws Varying by state, these laws have been successfully invoked against local authorities. (Castellanos v. City of Los Angeles; scattershot munition resulting in the loss of an eye). |
Law enforcement has a duty of care to the community. Therefore, violations can be considered torts, especially negligence (as opposed to crimes) in the face of foreseeable injury. |
Because Daniels v. Williams established that negligent acts by state officials do not violate constitutional due process, claims against federal officials for negligence must proceed under the FTCA. |
Labella v. United States (2024): A plaintiff, featured in PHR's 2020 study Shot in the Head, was shot in the forehead with a kinetic impact projectile by a deputy U.S. Marshal outside the federal courthouse in Portland. He filed suit for negligence, battery, and intentional infliction of emotional distress, all torts under the FTCA. The case settled out of court with the Department of Justice. |
Some individuals identified in our study have declared intent to file claims under the FTCA. |
How are crowd-control weapons being misused at immigration enforcement protests in the United States, and what patterns are reflected in the data with regards to responsible agency, location, weapons used, and types of harm?
June 1, 2025 – May 31, 2026
The United States
Retrospective, observational analysis with descriptive and comparative components.
| Time Trends | Incidents occurred in clusters in the cities where DHS announced, formally or informally, immigration raids. The raids were accompanied by large-scale protests, and, in many cases, these protests were met with a violent response. |
|---|---|
| The Impact of Leadership | Surges in violence during operations, including those in Los Angeles, Chicago, and Minneapolis, can be directly attributed to the leadership of Border Patrol agent Greg Bovino and his supervisors, particularly then-Secretary Kristi Noem. Each time Bovino was present at the site of major protests, incidents rose dramatically. |
| Weapons | Kinetic impact projectiles and chemical irritants made up the majority of the weapons used. However, hybrid weapons, including pepperballs and muzzle blasts, made up more than a third of the incidents. Additionally, the use of high-capacity foggers such as MK-9 OC spray demonstrates that weapons trends are changing over time, with weapons growing more potent and dangerous. |
| Agencies and Agents | While DHS agents were responsible for the deployment of force in most incidents, state, and local law enforcement agents — especially in Los Angeles — accounted for a third of the excessive force incidents. Notably, jurisdictions that enacted and sustained policing reforms saw far fewer local law enforcement incidents than those that reversed or abandoned them. |
| People and Injuries | Journalists, medics, and bystanders were injured alongside protesters. This holds serious implications for freedom of the press and raises concerns regarding freedom of assembly, especially given that even individuals who were not protesting — including journalists, legal observers and medics present in a professional capacity — were struck by crowd-control weapons. |
| Misuse of Force | In the vast majority of incidents, protests were peaceful before crowd-control weapons were deployed, and in all cases, basic standards of proportionality, precaution, and necessity were not met. |
| Policing Practices | Since the violence of 2020, significant progress has been made on crowd-control policies in the United States. The work that litigators, legislators, advocates, and human rights organizations have done to expose the violence and push for reform has not gone unheeded. Success has been uneven, and piecemeal reforms, however well-intentioned, cannot keep pace with what this report makes plain: the misuse of crowd-control weapons by law enforcement, and DHS agents in particular, is a nationwide phenomenon. Meaningful change requires broad action on regulation, training, and accountability. |
| Unfinished Business (Where You Come In) |
While this report has conducted in-depth analysis of the overall patterns and trends in the data, much remains to be done, beginning with additional analysis. To fill the gap in public reporting and monitoring mechanisms, local advocates could surface state- and city-level patterns. Many of the weapons identified in this report, including hybrid weapons and high-capacity foggers like the MK-9, also require dedicated research. Qualitative analysis of individual cases and case series could yield richer insights, particularly if the analyses center the voices of protesters, journalists, medics, and bystanders affected by these weapons. A de-identified version of the database is available for download, and the research team welcomes analysis by journalists, researchers, and students to further understand the full scope and impact of crowd-control weapons misuse as documented in this dataset. |
| Term | Definition |
|---|---|
| Crowd-control weapon | Any weapon, munition, or device deployed by law enforcement to disperse, deter, or otherwise manage groups of people. Crowd-control weapons are designed and marketed as an alternative to lethal force, intended to avoid causing grave harm or death. These weapons include chemical irritants, (e.g., tear gas, pepper spray, pepperball munitions), kinetic impact projectiles (e.g., rubber and plastic bullets, bean bags, scattershot munitions, sponge rounds, foam projectiles), batons, and flashbang or stun grenades. This definition also includes improvised uses of force involving tools commonly found at protests but not universally considered weapons, such as water cannons, acoustic hailing devices, warning/signaling munitions, horses, vehicles, and shields. Excluded are lethal weapons such as firearms, and hand-to-hand applications of force such as strikes, kicks, pushes, restraints, and other compliance techniques that do not involve a weapon. The term "Crowd-control weapons" is often used synonymously with "less-lethal weapons." PHR uses "crowd-control weapons" to specify weapons used in crowd settings rather than at individual arrests (such as Tasers) and to avoid rhetorically implying that these weapons are safe. Many law enforcement, legal, and manufacturer guidelines use "less-lethal weapons" for much the same category. |
| Use of force | Any physical action by a law enforcement officer or agent towards a person, including but not limited to deployment of a crowd-control weapons, striking, restraint, or physical violence. |
| Immigration enforcement protest | An assembly in which domestic immigration policy was an issue. This includes planned mass protests against federal immigration policy, spontaneous assemblies related to immigration enforcement operations, gatherings outside facilities known or suspected to be used for immigration enforcement operations, as well as other protests, such as the “No Kings” protests, in which immigration policy was a prominent factor.Protests were identified as immigration-related based on media characterization, witness statements, and visual analysis of signage and language. |
| Use of force incident | A use –of force event unique in time and location. Multiple media files (videos and photos) of the same event were consolidated into a single incident to prevent being counted more than once. |
| Open-source data | Publicly available information posted on the internet, including social media content, livestreams, news media, dashboard and body-cam footage, satellite imagery, and other user-generated material. |
| Geolocation | Verification of the physical location of an incident by matching images to satellite, street-view, and other geographic markers |
| Chronolocation | Verification of the date and time of an incident through metadata, shadow analysis, weather records, corroborating timestamps, and various visual signatures. |
| Misuse | International standards | Manufacturer guidelines | Police protocols |
|---|---|---|---|
| PROTECTED GROUPS: SAFEGUARDED BY PRINCIPLES OF Legality and precaution | |||
| Journalist | Guidance 2.10 At all times, law enforcement officials should consider and minimize the possible incidental impact of their use of force on bystanders, passers-by, medical personnel, and journalists. They shall not direct force against such persons, and any incidental impact must be strictly proportionate to the legitimate objective to be achieved. |
— | SPPD 438.19.8.D Journalists must not be targeted for dispersal or enforcement action because of their media status. |
| Healthcare worker / Legal observer | Guidance 2.10 At all times, law enforcement officials should consider and minimize the possible incidental impact of their use of force on bystanders, passers-by, medical personnel, and journalists. They shall not direct force against such persons, and any incidental impact must be strictly proportionate to the legitimate objective to be achieved. |
— | — |
| VULNERABLE INDIVIDUALS: SAFEGUARDED BY PRINCPLE OF PRECAUTION | |||
| Minor/ Elderly / Pregnant | Guidance 2.7 Law enforcement policies, instructions and operations must give special consideration to those who are particularly vulnerable to the harmful consequences of the use of force in general and to the effects of specific less-lethal weapons; such persons include children, pregnant women, the elderly, persons with disabilities, persons with mental health problems and persons under the influence of drugs or alcohol. |
— | LAPD UOF-1 p.3 [on objective reasonableness] Officer-subject interaction factors such as age, size, relative strength, skill level, injury/exhaustion, and number of officers versus subjects LASD 3-10/020.00 [on objective reasonableness] Factors such as age, size, relative strength, skill level, etc. CBP 3.B.4.c Authorized Officers/Agents should not use OC, and should consider other force options, with respect to subjects who are: small children; visibly pregnant; and operators of motor vehicles. SPPD 246.02.IX PepperBall should not be used in the following circumstances unless there are compelling reasons to do so that can be clearly articulated: When the subject is at the extremes of age (elderly and young children), physically disabled, or obviously pregnant CBP 3.B.7.d Authorized Officers/Agents should not use a compressed air launcher, and should consider other force options, on subjects who are: small children; elderly; visibly pregnant; or operating a conveyance. CBP 3.B.8.c Authorized Officers/Agents should not use an LLSI-CM and should consider other force options with respect to subjects who are: small children; elderly; visibly pregnant; near known flammable materials (when using a pyrotechnic device); or operating conveyances. Distraction Devices — CBP 3.B.9.c Authorized Officers/Agents should not use a CNLDD, and should consider other force options, on subjects who are: small children; elderly; visibly pregnant; or near known flammable materials. |
| Persons with disabilities | Guidance 2.7 Law enforcement policies, instructions and operations must give special consideration to those who are particularly vulnerable to the harmful consequences of the use of force in general and to the effects of specific less-lethal weapons; such persons include children, pregnant women, the elderly, persons with disabilities, persons with mental health problems and persons under the influence of drugs or alcohol. |
— | LAPD UOF-1 p.3 [on objective reasonableness] Whether the subject has any apparent physical or developmental disabilities LASD 3-10/020.00 [on objective reasonableness] Factors such as age, size, relative strength, skill level, etc. SPPD 246.02.IX PepperBall should not be used in the following circumstances unless there are compelling reasons to do so that can be clearly articulated: When the subject is at the extremes of age (elderly and young children), physically disabled, or obviously pregnant |
| IMPROPER USE OF FORCE: SAFEGUARDS FALL UNDER PRINCIPLES OF PRECAUTION, LEGALITY AND Proportionality | |||
| Shot to the head | Guidance 7.1.5 — Baton Officials should avoid baton strikes to sensitive areas of the body, such as the head, neck and throat Guidance 7.3.6 — KIP Projectiles should not be fired at the head or face Guidance 7.5.3 — KIP Targeting the face or head may result in skull fracture and brain injury, damage to the eyes, including permanent blindness, or even death. Guidance 7.5.8 — KIP Kinetic impact projectiles should not be targeted at the head, face, or neck. |
ASP Friction Baton — Baton Never target the subject’s head, face, or neck |
CBP 3.B.5.c(2) [prohibited acts] — Baton Intentional strikes with the baton to the head, the neck, the face, the groin, the solar plexus, the kidneys, or the spinal column. ICE 5.5.3.e.ii Fifth level (Deadly Force): Any use of impact weapons to strike the neck or head. LAPD UOF-6 p.3 officers should still make an effort to avoid striking the head, neck, throat, spine, kidneys, and groin areas to decrease the likelihood of causing serious injury. LASD 3-10/045.00 The following force options are prohibited unless deadly force is justified: All face, head, or neck strikes with an impact weapon. SPPD 246.02.VII During non-deadly force incidents, officers will use reasonable care to avoid striking subjects on the head, neck, sternum, spine, groin, or kidneys, as these strikes may constitute deadly force. CBP 3.B.7.g — KIP Authorized Officers/Agents shall not intentionally target the head, neck, spine, or groin of the intended subject, unless the use of deadly force is reasonable. CBP 3.B.8.d — KIP Authorized Officers/Agents shall not intentionally target the head, neck, groin, spine, or female breast. ICE 5.5.3.e.ii — KIP Any use of impact weapons to strike the neck or head LAPD UOF-3 p.2 — KIP The 40mm LLL shall not be used to target the head (e.g., face/eyes), neck, groin, spine, or kidneys unless lethal force is authorized. LAPD UOF-5 p.2 — KIP The FN303 shall not be used to target the head (e.g., face/eyes), neck, groin, spine, or kidneys unless lethal force is authorized. LASD 3-10/045.00 — KIP The following force options are prohibited unless deadly force is justified: All face, head, or neck strikes with an impact weapon LASD 5-06/040.15-20 — KIP The user shall not target the head or neck area when confronted with less than life-threatening situations. SPPD 246.02.IX — KIP Officers will not target the head, neck or spine unless a deadly force situation exists, and the use of force is within department policy and state statute. |
| Shot to the groin | — | — | CBP 3.B.7.g Authorized Officers/Agents shall not intentionally target the head, neck, spine, or groin of the intended subject, unless the use of deadly force is reasonable. CBP 3.B.8.d Authorized Officers/Agents shall not intentionally target the head, neck, groin, spine, or female breast. LAPD UOF-3 p.2 The 40mm LLL shall not be used to target the head (e.g., face/eyes), neck, groin, spine, or kidneys unless lethal force is authorized. LAPD UOF-5 p.2 The FN303 shall not be used to target the head (e.g., face/eyes), neck, groin, spine, or kidneys unless lethal force is authorized. SPPD 246.02.VII During non-deadly force incidents, officers will use reasonable care to avoid striking subjects on the head, neck, sternum, spine, groin, or kidneys, as these strikes may constitute deadly force. |
| Close range | Guidance 7.5.3 — KIP Targeting the torso may cause damage to vital organs, and there may be penetration of the body, especially when projectiles are fired at close range |
Tactical Diversionary Device — Distraction devices The cleared area for deployment should be 5 - 6 feet around which the device is expected to come to rest. MK-9 spray — Irritants Minimum Recommended distance: 6 feet MK-2 spray — Irritants Minimum Recommended distance: 3 feet "Muzzle Blast" — Irritants Minimum “effective range” 10 feet 40mm impact round — KIP Minimum safe range: 5 feet |
CBP 3.B.7.e — KIP Authorized Officers/Agents shall not use a PLS for kinetic impact on subjects less than 3 feet away unless the use of deadly force is reasonable and necessary. CBP 3.B.7.f — KIP The FN303 shall not be deployed if the officer/agent is less than 10 feet from the subject unless the use of deadly force is reasonable and necessary. LAPD UOF-3 p.2 The approved deployment range for the 40mm LLL is five (5) to 75 feet. LAPD UOF-12 p.2 The approved deployment range for the 37mm launchers is 10 to 50 feet from the front of the targeted individual(s). LASD 5-06/040.15 Minimum range for 40 mm ammunition is three feet for indirect fire (skip fire) and five feet for direct fire. LASD 5-06/040.20 Minimum range for the stunbag is 30 feet. LAPD UOF-7 p.2 — Irritants The approved range of OC is three to12 [sic] feet. |
| Direct fire | Guidance 7.3.6 — Chemical projectileIrritant projectiles should generally not be fired at an individual | 40mm Spede-Heat — Chemical projectiles Do NOT fire directly at personnel, as serious injury or death may result. 40mm Skat Shell — Chemical projectiles Do NOT fire directly at personnel, as serious injury or death may result. 40mm Warning/Signaling Munition — Distraction devices Do not fire directly at personnel, as serious injury or death may result. “Low Roll” Distraction Device — Distraction devices The cleared area for deployment should be 5 - 6 feet around which the device is expected to come to rest. |
LASD 5-06/40.25 — Distraction Devices Personnel using NFDD should avoid throwing grenades directly at individuals, in order to reduce the potential for flash burns or permanent hearing loss to the intended target when the grenade explodes. |
| Enclosed spaces / No egress | Guidance 7.3.7 — Chemical projectiles and grenades In general, chemical irritants should not be used in confined spaces, such as prison cells, where there is no viable exit or adequate ventilation, owing to the risk of death or serious injury from asphyxiation. Guidance 7.2.7 — Irritant spray Chemical irritants should not be used in closed environments without adequate ventilation or where there is no viable exit, owing to the risk of death or serious injury from asphyxiation. |
40mm Skat Shell — Chemical projectiles The 40mm Skat Shell® is designed for outdoor use and has fire producing capability. “Triple-Chaser” Grenade — Chemical grenades It should NOT be deployed onto rooftops, in crawl spaces, or indoors due to its fire-producing capability. Riot Control Grenade — Chemical grenades It should NOT be deployed onto rooftops, in crawl spaces, or indoors due to its fire-producing capability. Pocket Tactical Grenade — Chemical grenades It should NOT be deployed onto rooftops, in crawl spaces, or indoors due to its fire-producing capability. |
SPPD 438.19.6.B.7.a.2 Chemical munitions must be used only when: sufficient egress to safely allow the crowd to disperse exists |
| Shots without aiming | — | — | SPPD 438.19.6.B.5 Direct fired munitions may never be used indiscriminately against a crowd or group of persons even if some members of the crowd or group are violent or disruptive. |
| Improvised use | — | — | DHS 044-05-R01, IV.C DHS LEOs are prohibited from carrying any unauthorized less-lethal device for duty use LASD 3-10/065.00 In these rare and emergent circumstances, Department members may need to resort to improvised weapons or techniques. Any use of an improvised weapon must be objectively reasonable, proportional, and reasonably appear necessary under the totality of the circumstances. |
| Vehicle occupants | — | — | CBP 3.B.4.c [against drivers] Authorized Officers/Agents should not use OC, and should consider other force options, with respect to subjects who are: small children; visibly pregnant; and operators of motor vehicles. CBP 3.B.7.d [against drivers] Authorized Officers/Agents should not use a compressed air launcher, and should consider other force options, on subjects who are: small children; elderly; visibly pregnant; or operating a conveyance. CBP 3.B.8.c [against drivers] Authorized Officers/Agents should not use an LLSI-CM and should consider other force options with respect to subjects who are: small children; elderly; visibly pregnant; near known flammable materials (when using a pyrotechnic device); or operating conveyances. CBP 3.B.9.c [against drivers] Authorized Officers/Agents should not use a CNLDD, and should consider other force options, on subjects who are: small children; elderly; visibly pregnant; or near known flammable materials. SPPD 246.02.IX PepperBall should not be used in the following circumstances unless there are compelling reasons to do so that can be clearly articulated: When the subject is in control of a motor vehicle |
